IB-C160-AIR
The IB-C160-Air slit system has primarily found application within the neutron community. This extensive 18 kg slit system uses the same concepts as the other IB-slits but is reinforced to handle the significantly larger and heavier blades.
The standard blade materials are B4C or tungsten carbide. Other blades can be accommodated by JJ X-Ray or the customer.
Categories:
Technical Specifications
Aperture size
Maximum: 160 mm x 160 mm
Minimum: Full overlap
Resolution
1 micron per full step
Repeatability
< 2 micron
Accuracy
± 10 microns over the full range
± 1 micron or better with encoders
Limit switches (end-of-travel)
Included as standard on all motions
Guiding
High precision internal rails and carriages
Electrical connections
Limit switches coupled to 2 motor connectors (SUB-D 15 pins male)
Motors
2-phase stepping motors
Mechanical dimensions
556 mm x 556 mm x 78 mm (without extensions)
494 mm x 494 mm x 78 mm (housing only)
Mechanical connections
M6-threaded holes are on the sides, as shown in the drawing.
Weight
≈ 18.0 kg
Outer surface
Anodized aluminum in color nature
Common options
Blades: Various blade shapes and materials
Motors: Custom high-resolution stepping, including IMS motors
Encoders: Back-axle rotary encoders or internal Renishaw linear encoders (absolute or incremental)
Non-magnetic guides and lead screws and extension of motor housings for large distance
Custom connectors
