Slit Systems (X-rays / Neutrons)
Over the last 25 years, JJ X-Ray has designed a large portfolio of slit systems used at x-ray and neutron facilities all over the world. Our top priority is to give the customer the best solution whether they need the slit system to be standard, modified or customized.
Analyzer / Spectrometers
Read moreBeam
JJ X-Ray offers a range of cutting-edge products designed to enhance the precision and reliability of X-ray analysis systems. Diagnostic and analytic tools are essential for accurately measuring and analyzing X-ray beams, ensuring optimal performance across a variety of applications.
Collimators (X-rays / Neutrons)
All collimators are based on a custom design and are divided into three categories defined by the orientation of the foils.
Control Systems
JJ X-Ray provides comprehensive PLC solutions designed to enhance the integration and functionality beamline equipment. Our expertise in motion control and programmable logic controllers (PLCs) enables us to develop tailored automation systems that meet the specific demands in terms of precision and safety of scientific instrumentation in research environments.
Custom Solutions
When working on complex or custom projects, we always work in close collaboration with the customer to make sure all requirements are met, and projects are executed in a timely manner.
Full Beamlines
Read more
Fixed Masks
The white beam mask can be used in the front end or as a cost effective alternative to the white beam synchrotron slit. The white beam mask consists of two Cu alloy blocks with tapered square cutouts that can be moved vertically and latteraly such that each of the blocks from one-half of the vertical and one-half of the horizontal beam definition (like two L’s opposing each other).
Monochromators
JJ X-Ray A/S provides a range of monochromators designed for precise control of X-ray wavelengths in various research and industrial applications. Monochromators are essential for selecting specific wavelengths from an X-ray beam, improving the quality and resolution of diffraction and spectroscopy measurements.
Heavy Load Table
JJ X-Ray develops customized heavy load lifting stages due to increasing demands of high precision positioning combined with heavy load instrumentation in neutron and x-ray facilities. The lifting motion is achieved by four high precision screw jacks. The screw jack is driven by a flexible coupling that is connected to a gearbox and a stepper motor at the center. The synchronized lifting motion of the system is achieved through two identical gearboxes connected to both ends of the stepper motor’s spindle. The heavy load lifting stages are intended for heavy load applications to lift a single and/or a combination of instruments.
Design Features:
- Extreme load capacities, ranging from 500 kg to 5000 kg load according to customer requirements
- Self-locking lead screw allowing in-position stability
- Small footprint and customizable support base according to customer requirements
- Lifting motion achieved by one stepper motor – cost-efficient
- Flexible coupling motion transmission allows efficient transmission and no wear and tear contrary to belt transmission
Technical Specifications
Range/stroke
Upon customer request
Load capacity
500 kg to 5000 kg
Accuracy
10 µm*
Repeatability
1 µm*
Motion speed
0.8 mm/s*
Parasitic Motion (Pitch and Roll)
1.5 µrad/mm*
Linear encoder
Optional
*The values were obtained by motion tests at 50 mm range with 500 kg load in Open Loop operation, meaning that the motor’s position is commanded to move and stop at the nominal target positions without any feedback from a position sensor. By conducting the test in Open Loop, stepper motor failures, which most likely go undetected in Closed Loop operation, are easily identified.
